Professional Manufacturer Of All Kinds Of Terminal Blocks Horn Type Sockets
- Commodity name: RJ126-5.0
- Commodity ID: C-032
IEC/DIN VED Techinical data Rated insulation voltage 250V Rated current 18A Rated insulation voltageⅢ/3 - Rated insulation voltageⅢ/2 130V Rated insulation voltageⅢ/2 - Rated surge voltageⅢ/3 - Rated surge voltageⅢ/2 2kV Rated surge voltageⅢ/2 - UL Techinical data Rated insulation voltage(B) 300V Rated current(B) 8A Rated insulation voltage (C) - Rated current (C) - Rated insulation voltage(D) 300V Rated current(D) 8A Connection capacity Rigid conductor cross section 0.5-2.5mm2 Rigid conductor cross section 0.5-2.5mm2 Rigid conductor cross section 26-14AWG Mechanical Torque 0.2N.m(1.7Lb-In) Ambient temperature -40℃-+105℃ Stripping length 6-7mm
