Professional Manufacturer Of All Kinds Of Terminal Blocks Horn Type Sockets
- Commodity name: 2ERJKNM-5.0/5.08
- Commodity ID: B-046
IEC/DIN VED Techinical data Rated insulation voltage 320V Rated current 20A Rated insulation voltageⅢ/3 250V Rated insulation voltageⅢ/2 320V Rated insulation voltageⅢ/2 630V Rated surge voltageⅢ/3 1.6kV Rated surge voltageⅢ/2 1.6kV Rated surge voltageⅢ/2 1.6kV UL Techinical data Rated insulation voltage(B) 300V Rated current(B) 12A Rated insulation voltage (C) - Rated current (C) - Rated insulation voltage(D) 250V Rated current(D) 10A Connection capacity Rigid conductor cross section 0.2-2.5mm2 Rigid conductor cross section 0.2-2.5mm2 Rigid conductor cross section 24-14AWG Mechanical Torque - Ambient temperature -40℃-+105℃ Stripping length 10mm
Thank you for your attention to us. If you have any needs or comments, please leave us a message.
